Product Introduction
LY-800D Fixed Drone Detection Equipment is a device that integrates spectrum sensing and artificial intelligence technologies. It features flexible deployment and intelligent defense. The system can locate drone pilots, supports drone direction finding, and allows friendly drones to be added to a whitelist based on their unique serial numbers. If a drone not on the whitelist is detected, the system will automatically trigger an alarm.
Product Features
Application Scenarios
Performance Parameters
| Fixed Drone Detection Equipment | |||
| Product Model | LY-800D | Detection Type | Passive Detection |
| Product Functions | Drone Signal Detection,Drone Signal Analysis and Geolocation,Drone Signal Direction Finding,Whitelist and Blacklist,Flight Path / Trajectory Tracking | ||
| Protocol Analysis | Supports RID and DJI O1/O2/O3/O4 | Detection Frequency | 70-6000Mhz |
| Detection Radius | 5-10 km (Varies with environment and drone model) | Detection Sensitivity | -118DB |
| Detection Angle | 360° | Positioning Accuracy | ≤5m |
| Direction Finding Accuracy | ≤5°（RMS） | Simultaneous Detection Capacity | Simultaneous Detection Capacity: ≥50 Drones |
| Response Time | ≤5s | Rated Power | ≤60W |
| Power Supply Method | AC 220V | Communication Interface | RJ45 |
| IP Rating | IP65 | Main Unit Dimensions Weight | 400mm*500mm*400mm/≤12kg |
